Condylar Blade Plate 95


Condylar Blade Plate 95
Share On :Share On Google+ Share On Facebook Share on Twitter Pin on Pinterest

Model No: 605

Description

Condylar Blade Plate 95°

  • Specifications
  • Product Video

Condylar Blade Plate 95°, angle between blade and shaft. The two holes next to the blade are suitable for 6.5mm cancellous bone screws, all other holes are designed as dynamic selfcompressing holes. Fixation with 4.5mm cortex screws.

Shaft Profile
Thickness              5.6mm
Width                    16mm
Hole Spacing         16mm
U-Profile blade       6.5 x 16mm


Length
(mm)
Code - Stainless Steel
5 Holes 7 Holes 9 Holes 12 Holes 14 Holes 16 Holes 18 Holes
50 605.05.50 605.07.50 605.09.50 605.12.50 605.14.50 605.16.50 605.18.50
60 605.05.60 605.07.60 605.09.60 605.12.60 605.14.60 605.16.60 605.18.60
70 605.05.70 605.07.70 605.09.70 605.12.70 605.14.70 605.16.70 605.18.70
80 605.05.80 605.07.80 605.09.80 605.12.80 605.14.80 605.16.80 605.18.80
